Baomain Capacitive Proximity Sensor Switch LJC12A3-5-Z/BY PNP NO DC 10-30V 200mA 1-5mm Blue
12 sold in last 24 hours
- Product Name : Capacitive Proximity Switch; Model : LJC12A3-5-Z/BY; Wire Type : DC 3 Wire Type (Brown, Black, Blue); Switch Appearance Type : Cylinder Type
- Theory : Capacitance Sensor; Output Type : PNP NO(Normal Open); Diameter of Head : 12mm; Detecting Distance : 1-5mm
- Detecting Object : Metal or Nonmetal Material; Supply Voltage : DC 10-30V; Current Output : 200mA;
- Operating Temperature : -25 to +65 Celsuis (Non-freezing Condition); External Material : Plastic, Alloy
- Net Weight : 60g; Package Content : 1 x Capacitive Proximity Switch
Tags |
Estimated shipping
Select a product to estimate shipping.- It is a component widely used in automatic control industry for detecting, controlling, and noncontact switching.
- When proximity switch is close to some target object, it will send out control signal.
- As it is capacitive type proximity switch, its detecting object target is not limited to only conductor, but also liquid and even powder things, like plastic, water, glass, oil, etc.
- It is widely used in machine, paper making, light industry for limiting station, orientation taking count, speeding trial ect.
| Main Specification | |
|---|---|
| Materialmaterial | Plast or Metal or Alloy |
| Tillverkare | Baomain |
| Brand varumärke | Baomain |
| Färg | Blå |
| Punktvikt | 0,01 ounces |
| Product information | |
| Package Dimensions | 4.02 x 2.2 x 0.75 inches |
| Punktmodellnummer | LJC12A3-5-Z/BY |
| Technical Details | |
| Delnummer | LJC12A3-5-Z/BY |
| Others | |
| Datum först tillgänglig | 2016 2016 or February 23 |
| Produkttyp | Capacitive |
