Tools Ball Nose Carbide End Mill, MAH Coating, CNC Cutting Tools for Stainless Steel,Hardened Steels,High Temp Alloys,Medium Alloy Steels, 2 Flute,1/8" Shank,Inch Size (.125(1/8)", 5pcs)
14 sold in last 24 hours
- It is design for difficult cutting materials.Recommendation: high speed and low feed.Diameter tolerance 0 -0.02
- The core diameter is design more bigger to get stronger
- Material: Use ultramicron tungsten-carbide steel matrix,Perfect combination of toughness and hardness,Improve wear resistance while avoiding breakage and fracture
- Equipment: Manufactured with five-axis precision grinding machine, Each milling bit is tested by tool testing instruments,Good stability of dimensional accuracy
Tags |
Estimated shipping
Select a product to estimate shipping.These WEXWE ball nose end mills are engineered for precision machining of challenging materials like stainless steel and hardened alloys. They offer a robust solution for achieving smooth and accurate cuts in demanding applications.
Key Highlights
- Suitable for Difficult Materials: Designed for effective cutting of stainless steel, hardened steels, and high-temperature alloys.
- Precision Performance: Manufactured using a five-axis precision grinding machine, ensuring dimensional accuracy.
- Durable Construction: Crafted from ultramicron tungsten-carbide steel matrix, providing excellent wear resistance and minimizing breakage.
- Consistent Results: Each mill is tested using tool testing instruments for stable performance.
- Compact Size: The 1/8" shank size offers versatility for a range of CNC machines.
Useful Facts
- Diameter: 0.13 inches (Cutting Diameter)
- Shank Size: 1/8"
- Flutes: 2
- Material: Tungsten Carbide
- Quantity: 5 pieces
Good Fit For
- CNC Milling Machines
- Prototype Development
- Small-Scale Production
- Detailed Part Finishing
Product details
| Main Specification | |
|---|---|
| Tillverkare | WEXWE |
| Unit Count | 1.38 Ounce |
| Cutting Diameter | 0.13 Inches |
| Brand varumärke | WEXWE |
| Antal objekt | 5.5 5.5 5.5 |
| Cut Type | Ball End |
| Cutting Length | 0.13 inches |
| Shape | Runda |
| Technical Details | |
| Delnummer | BA2023411 |
| Materialtyp | Tungsten Carbide |
| Number of Flutes | 2 |
| End Cut Type | Ball End |
| Tolerance Held | Precision |
| Number of Cutting Edges | 2 |
| Style | |
| Finish Typer | TiAlN |
| Others | |
| Produkttyp | Ball Nose |
| Storlek Namn | 1/8"DIA - 3/8"FL - 1.5"OL 1/8Shank 5PC |
| Helix Angle | 3E+1 degrees |
